Article-Journal

Transferable Pre-Synthesis PPA Estimation for RTL Designs With Data Augmentation Techniques

In modern VLSI design flow, evaluating the quality of register-transfer level (RTL) designs involves time-consuming logic synthesis using EDA tools, a process that often slows down early optimization. While recent machine learning solutions offer some advancements, they typically struggle with maintaining high accuracy across any given RTL design. In this work, we propose an innovative transferable pre-synthesis PPA estimation framework named MasterRTL. It first converts the HDL code to a new bit-level design representation named the simple operator graph (SOG). By only adopting single-bit simple operators, this SOG proves to be a general representation that unifies different design types and styles. The SOG is also more similar to the target gate-level netlist, reducing the gap between RTL representation and netlist. In addition to the new SOG representation, Master-RTL proposes new ML methods for the RTL-stage modeling of timing, power, and area separately. Compared with state-of-theart solutions, the experiment on a comprehensive dataset with 90 different designs shows accuracy improvement by 0.33, 0.22, and 0.15 in correlation for total negative slack (TNS), worst negative slack (WNS), and power, respectively. Besides the prediction of synthesis results, MasterRTL also excels in accurately predicting layout-stage PPA based on RTL designs and in adapting across different technology nodes and process corners. Furthermore, we investigate two effective data augmentation techniques: a graph generation method and a Large Language Model (LLM)-based approach. Our results validate the effectiveness of the generated RTL designs in mitigating data shortage challenges.

Jan 1, 2025

RTLCoder: Fully Open-Source and Efficient LLM-Assisted RTL Code Generation Technique

The automatic generation of RTL code (e.g., Verilog) using natural language instructions and large language models (LLMs) has attracted significant research interest recently. However, most existing approaches heavily rely on commercial LLMs such as ChatGPT, while open-source LLMs tailored for this specific design generation task exhibit notably inferior performance. The absence of high-quality open-source solutions restricts the flexibility and data privacy of this emerging technique. In this study, we present a new customized LLM solution with a modest parameter count of only 7B, achieving better performance than GPT-3.5 on all representative benchmarks for RTL code generation. Especially, it outperforms GPT-4 in VerilogEval Machine benchmark. This remarkable balance between accuracy and efficiency is made possible by leveraging our new RTL code dataset and a customized LLM algorithm, both of which have been made fully open-source. Furthermore, we have successfully quantized our LLM to 4-bit with a total size of 4GB, enabling it to function on a single laptop with only slight performance degradation. This efficiency allows the RTL generator to serve as a local assistant for engineers, ensuring all design privacy concerns are addressed.

Jan 1, 2025

Large circuit models: opportunities and challenges

Within the electronic design automation (EDA) domain, artificial intelligence (AI)-driven solutions have emerged as formidable tools, yet they typically augment rather than redefine existing methodologies. These solutions often repurpose deep learning models from other domains, such as vision, text, and graph analytics, applying them to circuit design without tailoring to the unique complexities of electronic circuits. Such an “AI4EDA” approach falls short of achieving a holistic design synthesis and understanding, overlooking the intricate interplay of electrical, logical, and physical facets of circuit data. This study argues for a paradigm shift from AI4EDA towards AI-rooted EDA from the ground up, integrating AI at the core of the design process. Pivotal to this vision is the development of a multimodal circuit representation learning technique, poised to provide a comprehensive understanding by harmonizing and extracting insights from varied data sources, such as functional specifications, register-transfer level (RTL) designs, circuit netlists, and physical layouts. We champion the creation of large circuit models (LCMs) that are inherently multimodal, crafted to decode and express the rich semantics and structures of circuit data, thus fostering more resilient, efficient, and inventive design methodologies. Embracing this AI-rooted philosophy, we foresee a trajectory that transcends the current innovation plateau in EDA, igniting a profound “shift-left” in electronic design methodology. The envisioned advancements herald not just an evolution of existing EDA tools but a revolution, giving rise to novel instruments of design-tools that promise to radically enhance design productivity and inaugurate a new epoch where the optimization of circuit performance, power, and area (PPA) is achieved not incrementally, but through leaps that redefine the benchmarks of electronic systems’ capabilities.

Nov 1, 2024

r-map: Relating Implementation and Specification in Hardware Refinement Checking

Refinement checking is an important formal verification method that checks if a hardware implementation complies with (in other words, refines) a given specification. It has been widely used in processor and nonprocessor verification. In refinement checking, a refinement mapping is needed to relate the implementation and the specification. Despite the wide adoption of refinement checking, there is currently no general format or standard for the mapping—most prior works employed a certain property specification language (e.g., the SystemVerilog assertion) to write ad-hoc properties that describe the mapping relation. These manually written properties are usually not well structured and are often difficult to design or understand. In this article, we present r−map , a language for refinement mapping. r−map relates the implementation and the specification in a more concise and comprehensible way. We evaluate r−map in the refinement checking of practical hardware designs. In our case study, r−map shows a significant reduction of human efforts compared to manually writing refinement properties. We also show how r−map can help to scale up formal verification.

Jun 1, 2023

An Integrated Single-Shot Spectrometer With Large Bandwidth-Resolution Ratio and Wide Operation Temperature Range

There has been a rapidly growing demand for low-cost, integrated single-shot spectrometers to be embedded in portable intelligent devices. Even though significant progress has been made in this area, two major problems are still remaining, namely the high temperature sensitivity and poor bandwidth-resolution ratio (BRR) that can’t meet the requirement of most applications. In this work, we present an integrated single-shot spectrometer relying on a silicon photonic circuit that has a footprint less than 3mm2, but could achieve broad operation bandwidth about 100 nm and high resolution up to 0.1 nm (with a BRR ~ 1000). Moreover, for the first time, we demonstrate an integrated spectrometer that could operate within a wide temperature range (between 10 and 70 degrees Celsius) without additional power consumption for temperature management.

Jan 1, 2023

An example journal article
An example journal article

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Duis posuere tellus ac convallis placerat. Proin tincidunt magna sed ex sollicitudin condimentum.

Sep 1, 2015
